Technical specifications

unit data
Maximum bending

capacity/carbon steel

mm ≤Φ114*10 (customized)
Bending radius range mm ≤450
Maximum bending Angle Degree ≤190 °
Maximum feeding stroke mm 3200
Feed servo power kw 3
Feed rate Mm/s 650
Feeding accuracy mm ±0.1
Angle servo power kw 2
Angular velocity Deg/s 300
Angle accuracy Degree ±0.1
Hydraulic motor kw 22
System pressure Mpa 100
Equipment length * width * height mm ≈7500x1550x1600mm
Equipment weight Kg ≈10000

Usage

  • It is used for bending pipes and tubes at precise angles and curves instead of cutting and connecting them with fittings. This process preserves the pipe’s strength, saves time, and prevents deformation or damage.

  • It is widely used in several industries, including plumbing, heating, ventilation and air conditioning (HVAC) systems, metalworking and fabrication, metal furniture and chair manufacturing, construction and building, automotive manufacturing, and heavy industries such as offshore platforms, oil facilities, and power plants.
